F48-14M55-E, Timing Pulley

F48-14M55-E - Cast Iron Powerhouse®HTD® Pulleys

Product Details for F48-14M55-E

Comparable to: F48-14M55-E

F48-14M55-E, Timing Pulley, Cast Iron, Black Oxide,

Learn more about F48-14M55-E Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number F48-14M55-E
Teeth 48
Tooth Style HTD 14mm
For Belt Width (mm) 55.000
Material Cast Iron
Finish Black Oxide
Flange Material Steel
Bore Type QD
Bore (in) E
Pitch Diameter (in) 8.421
Outside Diameter (in) 8.311
Face Width (in) 2.750
Overall Length (in) 2.750
Min. Bore (in) 0.875
Unit System Inch
Bushing E
Max. Bore (in) 3.500
Weight (lb) 22.16
Part Number Cross Reference F48-14M55-E
