TL72XL037, Timing Pulley

TL72XL037, 78816072

TL72XL037

TL72XL037, 78816072 Line Drawing

Click to Enlarge

TL72XL037, Timing Pulley, Cast Iron, Black Oxide,

Learn more about TL72XL037 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number TL72XL037
Teeth 72
Tooth Style XL
For Belt Width (in) 0.3750
Type 8F
Material Ductile Iron
Finish Black Oxide
Flange Material Steel
Bore Type TL
Bore Description Bored for 1610 Bushing
Pitch Diameter (in) 4.584
Outside Diameter (in) 4.564
Unit System Inch
Bushing 1610
P.D. (mm) 116.00
O.D. (mm) 115.90
MOQ 1
Weight (lb) 2.90
Part Number Cross Reference TL72XL037, TL72XL037-1610 DYNA-SYNC SPKT, P72XL037-1610, TL72XL037, 113049, TL72XL037
