168-14P85-4040, Timing Pulley

168-14P85-4040 - Cast Iron Powerhouse® Pulleys

168-14P85-4040

Click to Enlarge

168-14P85-4040, Timing Pulley, Cast Iron, Black Oxide

Learn more about 168-14P85-4040 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 168-14P85-4040
Teeth 168
Tooth Style 14P
For Belt Width (mm) 85.00
Type D-3
Material Cast Iron
Finish Black Oxide
Bore Type TL
Bore Description Bored for 4040 Bushing
Pitch Diameter (in) 29.475
Outside Diameter (in) 29.365
Face Width (in) 4.000
Overall Length (in) 4.000
Min. Bore (in) 1.4375
Unit System Inch
Bushing 4040
P.D. (mm) 749.00
O.D. (mm) 745.90
MOQ 1
Weight (lb) 148.00
Part Number Cross Reference P168-14MGT-85, B16814M85TL, P168-14M-85-4040 HT250 SPKT, 168-14P85-4040, 114489, 168-14P85-4040
