18XL025M6FA8, Timing Pulley

18XL025M6FA8 - Aluminum Metric Pulleys

Product Details for 18XL025M6FA8

Comparable to: 18XL025M6FA8, A 6A3M018DF06008, A6A3M018DF06008

18XL025M6FA8, Timing Pulley, Aluminum, Clear Anodized

Learn more about 18XL025M6FA8 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 18XL025M6FA8
Teeth 18
Tooth Style XL
For Belt Width (in) 0.250
Type 6F
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (mm) 8.00
Set Screw 2 x M4 @ 90°
Pulley Belt Width (mm) 7.90
Unit System Inch
P.D. (mm) 29.10
O.D. (mm) 28.60
Flange Diameter (mm) 35.00
Face Width (mm) 11.10
Overall Length (mm) 17.50
Hub Diameter (mm) 21.00
Weight (lb) 0.06
Part Number Cross Reference 18XL025M6FA8, A 6A3M018DF06008, A6A3M018DF06008
