19-3M09-6A3, Timing Pulley

19-3M09-6A3

Click to Enlarge

19-3M09-6A3, Timing Pulley, Aluminum, Clear Anodized

Learn more about 19-3M09-6A3 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	19-3M09-6A3
Teeth	19
Tooth Style	HTD3mm
For Belt Width (mm)	9.00
Type	6
Material	Aluminum
Finish	Clear Anodized
Bore Type	Finished Bore
Bore (in)	0.250
Bore Description	1/4 Inch Finished Bore
Pitch Diameter (in)	0.714
Outside Diameter (in)	0.684
Face Width (in)	0.506
Overall Length (in)	0.812
Hub Diameter (in)	0.468
Min. Bore (in)	0.25
Unit System	Inch
P.D. (mm)	18.00
O.D. (mm)	17.40
MOQ	1
Weight (lb)	0.02
Part Number Cross Reference	A 6A23-019NF0908, A6A23-019NF0908, 19M3-L09M-6, PT019F08L09N, 19-3M09-6A3, 19-3M09-6A3
Set Screw Quantity	2
