22XL037M6A8, Timing Pulley

22XL037M6A8 - Aluminum Metric Pulleys

Product Details for 22XL037M6A8

Comparable to: 22XL037M6A8, A 6A3M22NF09508, A6A3M22NF09508

22XL037M6A8, Timing Pulley, Aluminum, Clear Anodized,

Learn more about 22XL037M6A8 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 22XL037M6A8
Teeth 22
Tooth Style XL
For Belt Width (in) 0.375
Type 6
Material Aluminum
Finish Clear Anodized
Flange Material Aluminum
Bore Type Finished Bore
Bore (mm) 8.00
Set Screw 2 x M4 @ 90°
Pulley Belt Width (mm) 9.50
Unit System Inch
P.D. (mm) 35.60
O.D. (mm) 35.10
Face Width (mm) 23.80
Overall Length (mm) 9.50
Hub Diameter (mm) 27.00
Weight (lb) 0.10
Part Number Cross Reference 22XL037M6A8, A 6A3M22NF09508, A6A3M22NF09508
