24L100-6FS7 Imperial Pitch Pulleys

24L100-6FS7, 24LB100, 114329

Product Details for 24L100-6FS7

Comparable to: 24L100-6FS7, 24LB100, 114329

24L100-6FS7, Timing Pulley, Powerhouse Timing, 5/8 Inch Bore, Steel

Specifications

Product Number 24L100-6FS7
Teeth 24
Tooth Style L
For Belt Width (in) 1.000
Type 6F
Material Steel
Finish Black Oxide
Flange Material Steel
Bore Type Minimum Plain Bore
Bore (in) 0.625
Pitch Diameter (in) 2.865
Outside Diameter (in) 2.835
Flange Diameter (in) 3.094
Face Width (in) 1.250
Overall Length (in) 1.750
Hub Diameter (in) 2.250
Min. Bore (in) 0.625
Pulley Belt Width (in) 1.070
Unit System Inch
Weight (lb) 2.50
List Price (1-9 Qty.) (USD) 38.96
Discount Price (10-24 Qty.) (USD) 35.06
Discount Price (25-49 Qty.) (USD) 30.68
Part Number Cross Reference 24L100-6FS7, 24LB100, 114329

Documentation

Download Catalog 2015_BBMAN_CATALOG_44.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 24L100-6FS7_REACH_cert
RoHS Certification 24L100-6FS7_RoHS_cert
