26-3M06-6A3 Powerhouse™ HTD® Pulleys

26-3M06-6A3, A 6A23-026NF0608

Product Details for 26-3M06-6A3

Comparable to: 26-3M06-6A3, A 6A23-026NF0608,

26-3M06-6A3, Timing Pulley, Powerhouse HTD, 1/4 Inch Bore, Aluminum

Specifications

Product Number 26-3M06-6A3
Teeth 26
Tooth Style HTD 3mm
For Belt Width (mm) 6.000
Type 6
Material Aluminum
Finish Clear Anodized
Bore Type Finished Bore
Bore (in) 0.25
Pitch Diameter (in) 0.977
Outside Diameter (in) 0.947
Face Width (in) 0.386
Overall Length (in) 0.691
Set Screw 2 x 8-32 @ 90°
Min. Bore (in) 0.25
Unit System Inch
Weight (lb) 0.04
List Price (1-9 Qty.) (USD) 9.43
Discount Price (10-24 Qty.) (USD) 8.96
Discount Price (25-49 Qty.) (USD) 7.08
Discount Price (50-99 Qty.) (USD) 5.66
Discount Price (100-249 Qty.) (USD) 4.95
Part Number Cross Reference 26-3M06-6A3, A 6A23-026NF0608,

Documentation

Download Catalog 2015_BBMAN_CATALOG_92.pdf
General Characteristics gen_char.html
Pulley Tolerances pulley_tol.html
Part Number Nomenclature Chart part_number_explain.pdf
Drive Alignment Guide proper alignment.pdf
For custom parts click here custom.html
REACH Certification 26-3M06-6A3_REACH_cert
RoHS Certification 26-3M06-6A3_RoHS_cert
