40B9 Minimum Plain Bore Sprockets

40B9

Product Details for 40B9

Comparable to: 40B9

40B9, Roller Chain Sprocket, 1/2 Inch Bore, Steel

Specifications

Product Number 40B9
Teeth 9
Tooth Style 40
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 1/2 Inch Minimum Plain Bore
Pitch Diameter (in) 1.462
Outside Diameter (in) 1.674
Face Width (in) 0.284
Overall Length (in) 0.875
Hub Diameter (in) 1.063
Min. Bore (in) 0.5
Unit System Inch
Weight (lb) 0.20
Part Number Cross Reference 40B9

Documentation

Download Catalog 2015_BBMAN_CATALOG_338.pdf
For custom parts click here custom.html
REACH Certification 40B9_REACH_cert
RoHS Certification 40B9_RoHS_cert
