60B24, Roller Chain Sprocket

60B24

60B24

60B24, Roller Chain Sprocket, Steel

Learn more about 60B24 Roller Chain Sprockets and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number 60B24
Teeth 24
Tooth Style 60
Type B
Material Steel
Bore Type Minimum Plain Bore
Bore (in) 3/4 Inch Minimum Plain Bore
Pitch Diameter (in) 5.746
Outside Diameter (in) 6.147
Face Width (in) 0.459
Overall Length (in) 1.250
Hub Diameter (in) 4.000
Min. Bore (in) 0.750
Unit System Inch
MOQ 1
Weight (lb) 5.78
Part Number Cross Reference 60B24, 60B24, 60B24, 74396045, 60B24, 60B24
