8B68SF, V-Belt Pulley

8B68SF

8B68SF, V-Belt Pulley, Cast Iron

B&B Manufacturing carries 8B68SF to accommodate the different industries we serve. Contact us today for a free quote!

Product Number	8B68SF
Type	A-1
Material	Cast Iron
Bore Type	QD
Bore Description	Bored for SF Bushing
Outside Diameter (in)	7.150
Face Width (in)	6.250
Min. Bore (in)	0.5
Unit System	Inch
Bushing	SF
MOQ	1
Sheave Type	A-B Combination
For Belt Type	A or B
Weight (lb)	25.00
Part Number Cross Reference	QD8A6.6/B6.8, 8B68.SF, 8B68-SF SHEAVE, 688B, 8B6.8, 6.8-8B-SF, B680/8SF, 8B68, 8BQ68, 8B68SF, 455745, 8B68SF
Grooves	8
