SS2424, Spur Gear

SS2424

SS2424, Spur Gear, Stainless Steel

Learn more about SS2424 Spur Gears and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number	SS2424
Teeth	24
Type	6
Material	Stainless Steel
Bore Type	Minimum Plain Bore
Bore (in)	0.250
Bore Description	1/4 Inch Minimum Plain Bore
Pitch Diameter (in)	1.000
Outside Diameter (in)	0.830
Face Width (in)	0.188
Overall Length (in)	0.437
Hub Diameter (in)	0.500
Unit System	Inch
MOQ	1
Weight (lb)	0.05
Part Number Cross Reference	S1268Z-024S024, SS2424, SS2424
Pressure Angle	20.0
Diametral Pitch	24
Set Screw Quantity	1
