TL60L075, Timing Pulley

TL60L075 - Cast Iron Imperial Pitch Pulleys

TL60L075

Click to Enlarge

TL60L075, Timing Pulley, Cast Iron, Black Oxide,

Learn more about TL60L075 Timing Pulleys and B&B Manufacturing, Inc. View product specifications, download a CAD file in your preferred format, or purchase online.

Specifications

Product Number TL60L075
Teeth 60
Tooth Style L
For Belt Width (in) 0.7500
Type 7
Material Cast Iron
Finish Black Oxide
Bore Type TL
Bore (in) 2012
Pitch Diameter (in) 7.162
Outside Diameter (in) 7.132
Face Width (in) 1.000
Overall Length (in) 1.250
Min. Bore (in) 0.500
Pulley Belt Width (in) 1.000
Unit System Inch
Bushing 2012
P.D. (mm) 182.00
O.D. (mm) 181.20
MOQ 1
Weight (lb) 4.90
Part Number Cross Reference TL60L075,  TB60L075 , 60 L 075 TL, 113534, TL60L075, TB 60-L-075, P60L075-2012, TL60L075
